Technical specifications

Serie	M3
Rated insulation voltage	250V
Thermal rated current	10A
Contact elements	1NO+1NC QUICK ACTION
Actuator type	STEEL WHEEL BUTTON ROTATED 90°
Material	PLASTIC BODY
Use	Industrial Automation
Code	M306NONC
