Technical specifications

Serie	M3
Rated insulation voltage	250V
Thermal rated current	10A
Contact elements	1NO+1NC QUICK ACTION
Actuator type	PLASTIC WHEEL PUSHBUTTON, LENGTH 26.6mm
Material	PLASTIC BODY
Use	Industrial Automation
Code	M311NONC
